Product Description
1.Product overview
Model: DL-3000 multifunctional crusher
This machine is specially designed for biomass raw materials such as bamboo and wood waste, branches, crop straws, etc.
It realizes the integrated processing of "cutting, hammering, and powdering" through high-speed rotating cutters.
It can crush 10mm-30mm raw materials into 1-8mm particles to meet the needs of fuel preparation, organic fertilizer processing, biomass power generation, etc.
Using high-carbon alloy steel blades and industrial-grade motors, it has both high-efficiency output and ultra-long life.
It is a reliable choice for large-scale production in factories and small-scale processing in rural areas.
2.Core advantages
(1) Efficient crushing
Multi-stage crushing system: The cutter and hammer are linked, the crushing efficiency is increased by 30%, and the production capacity reaches 500-800kg/h (depending on the density of raw materials).
Adjustable granules: By changing the screen (optional required), the output granularity can be flexibly controlled from 1-8mm.
2Industrial grade durable
High-carbon alloy steel blade: impact-resistant, wear-resistant, with a continuous operating life of over 2,000 hours.
Double bearing support: heavy-duty bearing + high-speed butter lubrication, stable operation, temperature rise 50.
3Safety first
Protective leather curtain + anti-splash design: The feed inlet is equipped with a wear-resistant leather curtain to prevent scraps from splashing.
Emergency shutdown: One-click power-off in case of abnormal vibration or material blockage to protect the safety of equipment and operators.
4Easy maintenance
Modular knife set: The blades can be quickly removed and replaced without the need for professional tools.
Belt tension adjustment: open belt compartment design, wear inspection and adjustment only takes 5 minutes.
3.Technical parameters
|
project
|
parameter
|
|
Applicable raw materials
|
Bamboo, wood, straw (moisture content 20%)
|
|
Maximum raw material size
|
300mm
|
|
Crushing particle size
|
1-8mm (adjustable screen)
|
|
Rated power
|
7.5kw
|
|
processing power
|
500-800kg/h
|
|
Equipment weight
|
280kg
|
4.Safe design
Triple protection: the feeding leather curtain prevents splashing, the motor is grounded to prevent leakage, and the belt bin protective cover prevents pinching.
Intelligent monitoring: automatic power off when overloaded to avoid motor burnout; alarm prompt for material blockage to quickly troubleshoot faults.
Operating specifications: Comes with a "Safety Operation Manual", which clearly indicates the prohibition of manual feeding and the need to wear protective gear.
5.Applicable scenarios
Biomass fuel plant: crush bamboo and wood waste into pellet fuel.
Organic fertilizer processing: straw and fruit tree branches are crushed and used for compost fermentation.
Rural cooperatives: handle agricultural and forestry waste and reduce transportation and storage costs.
Paper/board mill: preprocessing of raw materials to improve resource utilization.
6After-sales service
Free installation guidance and operation training are provided.
The core components have a 1-year warranty (the blades and screens are wearing parts and have a 3-month warranty).
Place your order now and enjoy the efficient conversion solution for bamboo and wood waste!
(Supports customized screen size to meet diverse particle needs)
Versatile Raw Material ProcessingEngineered to handle bamboo, wood, branches, and other biomass, this multi-functional crusher adapts to various raw material types with ease. The automatic grade system, adjustable output sizes, and high alloy steel wear-resistant blades ensure consistent and precise results, making it ideal for diverse applications in biomass industries and beyond.
User-Friendly Operation and MaintenanceOperating this crusher is streamlined by a one-button start and PLC control system, allowing for simple, efficient management. Designed for minimal maintenance, users spend less time on upkeep and more on productive tasks. Its durability means fewer interruptions, optimizing your operational workflow.
Safety and Environmental CompliancePrioritizing both operator safety and environmental protection, this machine meets established emission standards while maintaining a safe working noise level of 85 dB. The robust design and compliance assure peace of mind for users concerned about regulations and workplace wellbeing.
FAQ's of Certified Safety-10-30mm Raw Material Processing | High-Efficiency Alloy Steel Multi-functional Crusher | Bamboo/Wood/Branch Processing | Professional China Manufacturer:
Q: How does the Multi-functional Crusher adjust output size for processed materials?
A: The crusher allows you to adjust the output size between 10 mm and 30 mm, providing flexibility for different application needs. This adaptability ensures optimal results for bamboo, wood, branches, or biomass materials.
Q: What materials can be processed with this crusher?
A: It is designed for bamboo, wood, branches, and various biomass raw materials. Its alloy steel blades ensure efficient and consistent crushing of a wide range of input materials up to 300 mm in size.
Q: When is it ideal to use a stationary versus a mobile crusher setup?
A: A stationary unit is suitable for fixed plant operations with consistent material flows, while a customized mobile version is ideal for facilities requiring equipment movement or on-site material reduction at multiple locations.
Q: Where is this crusher manufactured and who is it ideal for?
A: Manufactured by a professional Chinese company, this crusher suits distributors, exporters, manufacturers, suppliers, and traders looking for reliable, high-capacity raw material processing solutions.
Q: What is the process for operating and maintaining the crusher?
A: Operation is simplified with a one-button start and PLC control. Regular maintenance involves basic checks and blade care, benefiting from the wear-resistant nature of the alloy steel blades and an intuitive design that minimizes service requirements.
Q: How does this crusher benefit users in biomass processing?
A: With a high throughput of 1000-1500 kg/h and adjustable output sizing, users experience increased productivity and material consistency, contributing to efficient downstream processing and versatility for various applications.
