Product Description

1.Product overview

Model: 1250-600 biomass comprehensive crusher

This machine is an advanced equipment specially designed for the processing of biomass raw materials. It integrates crushing and chipping functions.

It can efficiently process various raw materials such as small-diameter wood, bamboo, branches, straw, waste wood, etc.

It is suitable for biomass power plants, individual owners' material preparation, agricultural and forestry waste recycling and other fields.

Based on the optimization and upgrade of mature chipper technology, it combines high output, strong adaptability and convenient operation.

It is a benchmark product in the field of domestic biomass crushing.

2.Core advantages

(1) Super adaptable

Wide range of raw materials: supports the crushing of wood (branches, boards, wood cores) and non-wood (hemp stalks, reeds, corn stalks) raw materials.

Compound crushing: equipped with a "flying knife + bottom knife + crushing rod" system, which can crush large materials twice to ensure uniform discharge (the particle size is adjustable from 1-3mm).

(2) Efficient and stable

Powerful: 132kW main motor drive, 800mm cutter roller diameter, 3 flying knives for high-speed cutting, and production capacity leading similar products.

Dynamic balance design: The cutter roller has passed the G6.3 level dynamic balance test, running smoothly, with small vibration, and the bearing temperature rise is 40C.

(3) Intelligent control

Frequency conversion feeding: adjust the feeding speed in real time through the wireless remote control to match the main motor load to avoid material blockage or overload.

Interlocking protection: automatic reverse reversal when material is blocked, emergency stop button + multiple electrical protections to ensure safe operation.

4.Easy maintenance

Hydraulic opening: open the knife roller cover with one click and quickly replace the flying knife (2-3 days/time).

Modular design: The bottom knife base and screen can be pulled and disassembled as a whole, reducing maintenance time by 50%.

3.Technical parameters

project	parameter
Knife roller diameter	800mm
Main motor power	132kw
Feeding conveyor belt length	5 meters (optional chain plate/belt)
Maximum diameter of applicable raw materials	200mm
processing power	8-15 tons/hour (depending on raw materials)
Discharge particle size	1-3mm (adjustable)

4.Structural highlights

High-strength knife roller: Welded steel knife roller with high dynamic balancing accuracy and a service life of more than 5 years.

Dual pressing system: The upper and lower feeding rollers are designed with staggered teeth, the material is pressed evenly without stagnation, and the debris is self-cleaning.

Hydraulic buffer system: Nitrogen energy storage + oil cylinder linkage, automatically adapts to changes in material height, and operates without impact.

Multiple lubrication guarantees: The key bearing positions have external grease injection ports to support continuous operation lubrication (see the lubrication chart for cycles).

5.Safe design

Protective interlocking: triple safety mechanisms including power-off protection when opening the cover, emergency stop button, and motor overload protection.

Anti-loosening bolts: The flying knife/bed knife adopts high-strength special bolts (with "ZL" logo), which increase the shear resistance by 3 times.

Remote control: wireless remote control starts and stops the feeding, keeping away from the dangerous area of the feeding port.

6.Applicable scenarios

Biomass power plant fuel pretreatment

Wood processing plant waste recycling

Resource utilization of agricultural waste such as straw/cotton firewood

Landscaping branches smashed

7.After-sales service

Free installation guidance and operation training are provided.

The warranty period is 1 year (excluding wearing parts) and lifetime technical support.

Order now to enjoy efficient crushing solutions!

(Supports customized discharging device: air conveyor/scraper/elevator)

Precision Shredding for Multiple Applications

The Wood/Branch Shredder expertly reduces materials to uniform granules, benefiting industries such as pet bedding, animal feed, biomass, and organic fertilizer. Featuring strong 22 kW electric power, it is engineered for high-volume output with granule sizes tailored between 1 mm to 8 mm. Its automatic electric control mechanism streamlines operations, guaranteeing consistent results and making it suitable for commercial farms and processing plants.


Durability and Efficiency Combined

Constructed with a robust carbon steel body and equipped with alloy steel blades, this shredder ensures exceptional longevity and efficiency. The screw diameter of 200 mm and weight of 1280 kg underscore its industrial-grade capability. Designed for easy integration and reliable daily use, it minimizes maintenance downtime and maximizes productivity, making it an ideal choice for distributors and traders seeking reliable equipment.
